Classification Characteristics and Device Requirements of Cable Bridge Frames

电缆桥架可以分爲槽式、托盘式与梯架式，网格式等等，它是由支架，托臂与装置附件所组成，电缆桥架的品种有什麼?装置要留意些什麼?以上去爲大家阐明电缆桥架的分类跟装置要求。

Cable bridge can be divided into trough type, tray type and ladder type, grid type and so on. It is composed of bracket, bracket and device accessories. What kind of cable bridge? What should the device pay attention to? The above is to clarify the classification and device requirements of cable bridge.

1、梯阶式电缆桥架

1. Stepped Cable Bridge

梯级式电缆桥架是按照着及国外的相关材料，改良设计的，这种桥架运用起来本钱比拟低，搬起来分量轻，造型比拟特别，散热好且透气佳，通常用在直径比拟大的电缆，较爲合适高或是高压动力电缆。

The cascade cable bridge is improved and designed according to the international and foreign related materials. This kind of bridge has low cost, light lifting weight, special shape, good heat dissipation and good ventilation. It is usually used in cables with large diameter, which are suitable for high-voltage power cables or high-voltage power cables.

2、托盘式电缆桥架

2. Tray Cable Bridge

优点是分量很轻，负分量很大，造型美观而且构造很简洁，装置也不大困难，通常用在石油，化工，轻工，电讯等，合适动力电缆的装置，也可以用于控制电缆。

The advantages are light weight, large negative weight, beautiful appearance and simple structure, and the device is not too difficult. It is usually used in petroleum, chemical industry, light industry, telecommunications, suitable power cable devices, can also be used for control cables.

电缆桥架的分类特点和装置要求

Classification Characteristics and Device Requirements of Cable Bridge Frames

3、槽式电缆桥架

3. Trough Cable Bridge

这是一种完全封锁的电缆桥架，合适有高灵敏零碎的控制电缆，像是计算机电缆，通讯电缆等等，它可以很无效的屏蔽控制电缆的搅扰，与环境中的重腐蚀，有超级好的维护效果。

This is a completely blocked cable bridge. It is most suitable for high sensitive and fragmentary control cables, such as computer cables, communication cables, etc. It can effectively shield the disturbance of control cables, heavy corrosion in the environment, and has super good maintenance effect.

4、大跨距电缆桥架

4. Long Span Cable Bridge Frame

运用寿命长，且装置比拟复杂，本钱比拟低，切割容易，是不需求维护，运用起来特别的方便，它是由拉挤玻璃钢型材组装起来的，可以用在电力电缆，控制电缆，照明电缆或是其他配件上。

The utility model has the advantages of long service life, complex device comparison, low cost comparison, easy cutting, no maintenance requirement and special convenience in use. It is assembled by pultruded FRP profiles and can be used in power cables, control cables, lighting cables or other accessories.

5、组合式电缆桥架

5. Composite cable bridge

电缆桥架的分类特点和装置要求

Classification Characteristics and Device Requirements of Cable Bridge Frames

照着现场的装置随意转向，可以变宽，分引上，引下，在随意的部位不必打孔，不必焊接就把可用管引出，它是属于一种新型的桥架，是电缆桥架中的第二代新产品，运用于各项工程，各个单位，方便工程中的设计，也方便消费时的运输，是一个很的产品。

It is a new type of bridge frame and the second generation of new products in cable bridge frame. It is used in various projects, units, convenient for design in engineering, and convenient for transportation in consumption. It is a very excellent product.

装置要求

Device requirements

1、电缆桥架跟要用电的设备遇到时，间距要大于0.5公尺。

1. The distance between the cable bridge and the equipment to be used should be greater than 0.5 meters.

2、两组电缆在同一个高度平行时，间距要大于0.6公尺。

2. When two groups of cables are parallel at the same height, the spacing should be greater than 0.6 meters.

3、布放在线槽的缆线时，线槽外面的缆线要顺直。

3. When laying the cable in the groove, the cable outside the groove should be straight.

4、在吊顶外面设置的时分，槽盖开启的那一面要坚持80毫米的垂直净空，线槽截面的应用率要小于百分之五十。

4. When setting outside the ceiling, the opening side of the groove cover should adhere to the vertical clearance of 80 mm, and the application rate of the line groove section should be less than 50%.

综上所述有济南航丰实业有限公司提供，更多山东电缆桥架知识，欢迎关注我们的网站：http://www.sdhangfeng.com谢谢支持!

In summary, Jinan Hangfeng Industrial Co., Ltd. provides more knowledge of Shandong cable bridge. Welcome to our website: http://www.sdhangfeng.com. Thank you for your support!
