1. As a supporting project of wiring engineering, cable tray has no special standard guidance at present, and the specifications and procedures of individual consumer manufacturers are lack of generality. Therefore, the design and selection process should be based on the type and quantity of each weak current system cable, and the appropriate cable tray should be selected reasonably.

　　(1)确定方向： 依据建筑平面布置图,分离空调管线和电气管线等设置状况、便当维修,以及电缆路由的疏密来肯定电缆桥架的更佳路由。在室内,尽可能沿建筑物的墙、柱、梁及楼板架设,多么应用综合管廊架设时,则应在管道一侧或上方平行架设,并思索引下线和分支线尽量防止穿插,如无其它管架借用,则需自设立(支)柱。

　　(1) confirm the direction: according to the building layout, separate the air conditioning pipeline and electrical pipeline and other settings, convenient maintenance, and the density of the cable route to determine the best route of the cable bridge. In the room, it shall be erected along the wall, column, beam and floor of the building as much as possible. When the comprehensive pipe gallery is used for erection, it shall be erected in parallel on one side or above the pipe, and the index down line and branch line shall be considered to prevent interpenetration as much as possible. If there is no other pipe frame for borrowing, it is necessary to set up (support) the column by itself.

　　(2)荷载计算：计算电缆桥架主干线纵断面上单位长度的电缆重量。

　　(2) load calculation: calculate the cable weight per unit length on the vertical section of the main line of the cable bridge.

　　(3)确定桥架的宽度：依据布放电缆条数、电缆直径及电缆的间距来肯定电缆桥架的型号、规格, 托臂的长度,支柱的长度、间距,桥架的宽度和层数。

　　(3) confirm the width of the bridge: confirm the model and specification of the cable bridge, the length of the support arm, the length and spacing of the pillar, the width and the number of layers of the bridge according to the number of cables laid, the diameter of the cable and the distance between the cables.

　　(4)确定装置方式：依据场所的设置条件肯定桥架的固定方式,选择悬吊式、直立式、侧壁式或是混合式,衔接件和紧固件普通是配套供给的,此外,依据桥架构造选折相应的盖板。

　　(4) positive device mode: according to the setting conditions of the site, confirm the fixing mode of the bridge, select the suspension type, vertical type, side wall type or hybrid type, and the connectors and fasteners are generally supplied together. In addition, select and fold the corresponding cover plate according to the structure of the bridge.

　　(5)绘出电缆桥架平、剖面图,部分部位还应绘出空间图,开列资料表。

　　(5) draw the plan and section drawing of cable bridge, and draw the space drawing and list the data sheet for some parts.

　　2、如与电力电缆桥架合用时,应将电力电缆和弱电电缆各直一侧,中间采用隔板分隔。

　　2. If it is used together with the power cable bridge, the power cable and the weak current cable shall be separated on each straight side by a partition.

　　3、弱电电缆与其它低电压电缆合用桥架时,应严厉执行选择具有外屏蔽层的弱电系统的弱电电缆,防止互相间的干扰。

　　3. When the weak current cable and other low-voltage cables share the bridge, the weak current cable of the weak current system with external shielding layer shall be strictly selected to prevent interference between the phases.

　　4、电缆桥架装置请求

　　4. Cable tray device request

　　(1)槽式大跨距电缆桥架由室外进入建筑物内时,桥架向外的坡度不得小于1/100。(2)电缆桥架与用电设备交越时,其间的净距不小于0.5m。

　　(1) when the trough type long-span cable bridge enters the building from the outside, the slope of the bridge outward shall not be less than 1 / 100. (2) when the cable bridge crosses the electrical equipment, the clear distance between them shall not be less than 0.5m.

　　(3)两组电缆桥架在同一高度平行敷设时,其间净距不小于0.6m。(4)在平行图上绘出桥架的路由,要注明桥架起点、终点、拐弯点、分支点及升降点的坐标或定位尺寸、标高,如能绘制桥架敷设轴侧图,则对资料统计将更准确。

　　(3) when two groups of cable bridges are laid in parallel at the same height, the clear distance between them shall not be less than 0.6m. (4) draw the route of the bridge on the parallel diagram, and indicate the coordinates, positioning dimensions and elevation of the starting point, terminal point, turning point, branch point and lifting point of the bridge. If the axial side diagram of the bridge laying can be drawn, the data statistics will be more accurate.

　　直线段：注明全长、桥架层数、标高、型号及规格。拐弯点和分支点:注明所用转弯接板的型号及规格。升降段：注明标高变化,也可用部分大样图或剖面图表示。

　　Straight line section: indicate the total length, number of bridge layers, elevation, model and specification. Turning point and branch point: indicate the model and specification of the used turning joint plate. Lifting section: indicate the elevation change, which can also be represented by partial detail drawing or section drawing.

　　(5)桥架支撑点, 如立柱、托臂或非规范支、构架的间距、装置方式、型号规格、标高,可同意在平面上列表阐明,也可分段标出用不同的剖面图、单线图或大样图表示。

　　(5) the support points of the bridge, such as the spacing, installation mode, model, specification and elevation of the column, support arm or non-standard support and framework, can be agreed to be listed on the plan, or marked in sections and represented by different sections, single line drawings or detailed drawings.

　　(6)电缆引下点位置及引下方式,普通而言,大批电缆引下可用垂直弯接板和垂直引上架,少量电缆引下可用导板或引管,注明引下方式即可。

　　(6) the location and method of cable downlead point. Generally speaking, a large number of cables can be downlead with vertical bending plate and vertical downlead frame, while a small number of cables can be downlead with guide plate or downlead pipe, indicating the downlead method.

　　(7)电缆桥架宜高出空中2.2米以上,桥架顶部距顶棚或其它障碍物不应小于0.3米,桥架宽度不宜小于0.1米,桥架内横断面的填充率不应超越50%。

　　(7) the cable bridge should be 2.2m higher than the air, the distance between the top of the bridge and the ceiling or other obstacles should not be less than 0.3m, the width of the bridge should not be less than 0.1M, and the filling rate of the cross section in the bridge should not exceed 50%.

　　(8)电缆桥架内缆线垂直敷设时,在缆线的上端和每距离1.5米处应固定在桥架的支架上,程度敷设时, 在缆线的首、尾、转弯及每距离3~5米处停止固定。

　　(8) when the cables in the cable tray are laid vertically, they shall be fixed on the bracket of the tray at the upper end of the cable and at every distance of 1.5m. When laying to a certain extent, they shall be stopped at the head, tail, turn and every distance of 3-5M.
