At present, Shandong bridge is very popular in the construction power industry. With the application of the bridge from time to time, more and more people choose to install the bridge, and pay more and more attention to it. Do you know the cable arrangement methods of the bridge and distribution frame? Today, Jinan cable bridge factory is here to introduce you.

　　先要整理桥架上的线缆：普通状况下，整理楼层桥架中的线缆并不是很艰难，只需直接顺着它的方向理顺整理即可，不需停止捆扎。另外，主干桥架中的线缆则需求运用扎带停止简单的捆扎，用来区别不同的楼层，并减少重力拉伸线缆，从而防止改动桥架物理属性(绞合度、长度等)和电气性能。

　　First, the cables on the bridge should be sorted out: under normal conditions, it is not very difficult to sort out the cables in the floor bridge, just straighten out the cables in its direction, without stopping binding. In addition, the cables in the trunk bridge need to stop simple bundling with ties to distinguish different floors, and reduce the gravity tension of the cables, so as to prevent changes in the physical properties (stranding, length, etc.) and electrical performance of the bridge.

　　桥架

　　Bridge frame

　　其次是如何整理配线架中的线缆,这局部需求细分为两小节：

　　Secondly, how to sort out the cables in the distribution frame is divided into two sections:

　　1、整理前面板线缆

　　1. Arrange the front panel cable

　　假如交流机与配线架位于同一机柜中，则只需选择恰当长度的跳线，将跳线打个环后置于理线器中。

　　If the AC machine and distribution frame are located in the same cabinet, only the jumper of appropriate length should be selected, and the jumper should be placed in the wire manager after looping.

　　然后，两端分别衔接交流机和配线架端口,一切衔接都完成后，盖上理线器的盖板即可,假如配线架与交流机位于不同的机柜，那么需求运用较长的跳线需求对跳线停止整理。除了配线架和交流机的前面板需求运用理线器对线缆停止整理外，垂直局部也应当运用垂直理线器停止整理。

　　Then, the two ends are connected to the port of the AC machine and the distribution frame respectively. After all the connections are completed, cover the cover plate of the cable manager. If the distribution frame and the AC machine are located in different cabinets, long jumpers are required to be used to stop the arrangement of jumpers. In addition to the front panel of the distribution frame and the AC machine, the cable manager shall be used to stop the cable sorting, and the vertical part shall also be used to stop the sorting.

　　2、整理后部线缆

　　2. Arrange the rear cable

　　配线架后部集中着网络布线系统中的一切程度布线，因而有大量的线缆需求整理。在通常状况下，每一个配线架中的线缆在理顺之后，应当运用尼龙扎带依次捆扎固定。

　　At the back of the distribution frame, there are all levels of cabling in the network cabling system, so there is a large number of cable needs to be sorted out. In general, the cables in each distribution frame shall be tied and fixed in turn with nylon ties after being straightened out.

　　桥架

　　Bridge frame

　　程度线缆的捆扎固定方向应当左右交替，以便于垂直局部固定在机柜两侧。然后，再将一切垂直局部线缆依次捆扎固定在机柜的两侧。在捆扎固定线缆时，应当留意不要过火折弯双绞线，并且扎带不要扎得过紧，以免影响线缆的电气性能。

　　The binding and fixing direction of the cable shall be left and right alternately to facilitate the vertical partial fixation on both sides of the cabinet. Then, tie and fix all vertical local cables on both sides of the cabinet in turn. When binding and fixing the cable, pay attention not to bend the twisted pair too much, and do not tie the cable too tightly to avoid affecting the electrical performance of the cable.

　　上述就是济南电缆桥架厂为大家引见的山东桥架和配线架的线缆整理技巧，置信大家看完之后对桥架有了进一步的理解和认知，希望以上内容能对大家有所协助，想理解更多详情，欢迎访问网站：http://www.sdhangfeng.com

　　The above is the cable arrangement skills of Shandong cable tray and distribution frame introduced by Jinan cable tray factory for you. I believe you have a further understanding and cognition of the cable tray after reading it. I hope that the above content can help you. If you want to understand more details, please visit the website: http://www.sdhangfeng.com
