1、 Unique insulation structure

　　1.采用气体绝缘材料，提高整体绝缘和超重母线槽容量。

　　1. Adopt high-quality gas insulation materials to improve the overall insulation and overweight bus duct capacity.

　　2.采用特殊的生产高性能耐热防火绝缘支持框架,综合绝缘支撑架装饰切断之间的连接总线和罩壳,这保证了系统软件加载或火灾时效率高、隔热能力,提高整体的冲击韧性。

　　2. The special production high-performance heat-resistant and fire-resistant safety insulation support frame is adopted, and the connection bus and cover between the decoration and cutting of the integrated insulation support frame are integrated, which ensures the high efficiency of system software loading or fire aging, energy-saving and heat insulation ability, and improves the overall impact toughness.

　　二、总体结构性能高

　　2、 High overall structural performance

　　1.所有的汇流排由一个综合的绝缘支撑架垂直放置和夹紧。Q235碳钢高强度装饰条与挡板连接形成自身本体，保证了整个系统软件的高强度性能。

　　1. All busbars are vertically placed and clamped by an integrated insulating support frame. Q235 carbon steel high-strength decorative strip and baffle are connected to form its own body, which ensures the high-strength performance of the whole system software.

　　2.外螺纹花在绝缘支撑架和中间紧地脚螺栓是相互匹配、相互加强,这样没有人能阻止公车滑落时垂直安装,从而实现高强度性能的总体结构设计理念。

　　2. The external thread is matched and strengthened with the insulating support frame and the intermediate anchor bolt, so that no one can prevent the vertical installation when the bus falls, so as to realize the overall structural design concept of high-strength performance.

　　三、热管散热结构

　　3、 High quality heat pipe cooling structure

　　空气的母线槽系统软件热管冷却方法大多是“热对流和辐射来源”的热管冷却方法,根据热管冷却方法的热导率是缓慢的,因此,电气设备外壳设计采用波状纹理,收集波粒铝覆盖的设计构思,合理改善了热管散热效率。

　　The cooling method of air bus duct system software heat pipe is mostly the heat pipe cooling method of "heat convection and radiation source". According to the heat pipe cooling method, the thermal conductivity is slow. Therefore, the design of electrical equipment shell adopts wave texture, collecting wave grain aluminum to cover the overall design structure, and reasonably improves the heat pipe cooling efficiency.

　　四、防水等级

　　4、 High quality waterproof grade

　　因为使用一个独特的“业务外包”接近每一个其他类型的后盖结构,没有固定地脚螺栓在后盖的表面,不仅漂亮和优雅干净,并避免雾入水中,进一步提高公共汽车频道防水级别,IP65等级。

　　Because a unique "business outsourcing" approach to every other type of back cover structure, there is no fixed anchor bolt on the surface of the back cover, which is not only beautiful and elegant and clean, but also avoids fog entering the water, further improving the waterproof level of bus channel, IP65 level.

　　五、非凡预防“烟囱效应、风管效应”封顶

　　5、 Special prevention "chimney effect, air duct effect" capping

　　的耐热的母线槽是改装插头每个母线管道泄漏的顶部,以便所有系统软件可以根据的热管散热,防止加热的“烟囱效应”母线槽系统软件安装时垂直和水平安装时加热管效应。

　　The heat-resistant bus duct is the top of the leakage of each bus duct of the retrofit plug, so that all system software can dissipate heat according to the heat pipe, and prevent the heating pipe effect when the heating "chimney effect" bus duct system software is installed vertically and horizontally.

　　六、高电导率的导体设备

　　6、 Conductor equipment with high conductivity

　　电导体采用T2电工接地铜棒，铜水含量大于99.9%，接地铜棒电导体表面镀铅锌或镀金，不仅降低了接触电阻，还提高了母线电缆的负荷流量。

　　High quality T2 international electrical grounding copper bar is used as the electric conductor, with copper water content more than 99.9%. Lead zinc or gold plating on the surface of the grounding copper bar electric conductor not only reduces the contact resistance, but also improves the load flow of the bus cable.

　　七、不同的插入点配双插头插座设备

　　7、 Double plug and socket equipment for different insertion points

　　1.该千斤顶采用“”触线结构，母线支头既能满足小电流的连接插入需要，又能满足工业生产中大电流的连接插入需要。合理地摆脱了传统插入角易烧尽、损伤后不易就地修复的缺点。

　　1. The jack adopts the "zero distance" contact wire structure, and the bus support head can not only meet the connection and insertion needs of small current, but also meet the connection and insertion needs of large current in industrial production. It is reasonable to get rid of the shortcomings of the traditional insertion angle, which is easy to burn out and difficult to repair in place after damage.

　　2.如果连接箱的电源开关3 p,当电源开关,电气设备将N, PE阶段后杰克部分放置在电源开关,进入统一的箱电缆连接终端,进一步提高工作效率,还很多铺张浪费,减少电缆客户为客户节省大量隐形的运营成本。

　　2. If the power switch 3P of the connection box is used, when the power switch is used, the electrical equipment will place the jack part in the power switch after the N, PE stage, and enter the unified box cable connection terminal, further improving the work efficiency, and reducing a lot of extravagance and waste, so as to save a lot of invisible operating costs for customers.

　　以上是电缆桥架制造商为大家介绍的相关内容，想要了解更多内容，欢迎访问网站：http://www.sdhangfeng.com

　　These are the relevant contents introduced by the cable tray manufacturer. For more information, please visit the website: http://www.sdhangfeng.com
